PMMA Lens Coating

HCG-150 AC Lens Hardcoating Sol (Primerless)

  • Product Details

HCG-150 AC Lens Hardcoating Sol (PRIMERLESS) is a proprietary formulation of thermally curable polysiloxane resins in alcohol solvent. Typical use could be found on acrylic lens hardcoating which forms a thin optically clear layer with superior resistance to scratch and abrasion. Users could enormously benefit from the ease of handling and reduced operational cost as HCG-150 does not require a primer to achieve adhesion.

1. Basic Specification

Property

Unit

Values

Method

Coating Sol



Density

g/ml

0.925-0.935

Gravitometer @ 20

Viscosity

cp

5—10

rotatory viscometer @ 20

Solid Content

%

25—27

180, 30min

PH Value

-

4—6

PH meter @ 20

Cured Film



Pencil Hardness

H

4H

750g load, Mitsubishi Pencil

Adhesion

-

Pass

Crosshatched, 3M 810 tape

Scratch Resistance

-

negligible

0000#steel wool,200g load, 40 cycles

Hot Water Resistance

-

Pass

80, 30min

Light Transmission

-

93

%

2. Production Environment

Working Temp.: 18°C-22°C (coating liquid temp. is required to be 3 Celsius lower than room temp.)

RH: 40%-60%

Clean Room: class 1000-10000
